J.Juan Radial Brake Caliper for Pitbikes

Application

• 85GP and Moto 4 motorcycles

• Under 250cc

Main features:

• Compact and lightweight caliper with 4x25mm pistons

• Hard anodized aluminum pistons Die cast bodies

• Race Hollow Bolts

• Spring-loaded pad design for minimal torque

• Organic pads specially designed for light track motorcycles

• Self-lubricating EPDM square piston seal for maximum piston sliding properties

• Moto GP Technology

• For use with DOT 4 and DOT 5.1 racing brake fluid

For OEM

• Adaptability to all models

• Easy and simple installation

• Long lasting

• Low maintenance

• Excellent quality – price

For distributor

• Suitable for all models

• Easy to install

• Very interesting margin for the distributor

• Permanent stock

• Great budget price

for the consumer

• The highest braking technology directly from Moto GP

• Suitable for all motorcycle models

• Product validated with laboratory and vehicle tests

• Low maintenance

• Excellent quality-price ratio

LIGHTWEIGHT CALIPER Minimum unsprung mass

BRAKE PAD OPTIONS Organic Compounds for 85GP and Moto 4 classes

RIGHT AND LEFT POSITION Both positions are available

DIE-CAST CALIPER WITH 82mm WHEELBASE Aluminium body with anodic oxidation treatment

General Description

- Left and right caliper 4xØ25mm with 82mm center distance and 20mm offset.

Mounting position between 9pm and 12am

-Construction. Gravity-cast aluminum alloy bodies and stamped threaded pin with tool-free clips. The pads are supported by the caliper body itself. Matte black anodized.

-Lightweight hard anodized aluminum pistons with ground outer diameter

- Square and dustproof EPDM seals with refined groove design

BRAKE PAD OPTIONS:

The caliper comes with pads

M10 x 1.00 Banjo Socket
